ESD7241N2T5G ESD Suppressors / TVS Diodes 24V VRWM ESD PROTECTION

1.The ESD7241 is designed to protect voltage sensitive componentsthat require ultra−low capacitance from ESD and transient voltageevents. It has industry leading capacitance linearity over voltagemaking it ideal for RF applications. This capacitance linearitycombined with the extremely small package and low insertion lossmakes this part well suited for use in antenna line applications forwireless handsets and terminals.

2.Features
•Industry Leading Capacitance Linearity Over Voltage
•Ultra−Low Capacitance: < 1.0 pF Max
•Insertion Loss: 0.15 dB at 1 GHz; 0.60 dB at 3 GHz
•Low Leakage: < 0.5 uA
•Protection for the following IEC Standards:
♦IEC61000−4−2 (ESD): Level 4 ±28 kV Contact
♦IEC61000−4−4 (EFT): 40 A −5/50 ns
♦IEC61000−4−5 (Lightning): 2.5 A (8/20 s)
•SZESD7241MXWT5G − Wettable Flank Package for OptimalAutomated Optical Inspection (AOI)
•SZ Prefix for Automotive and Other Applications Requiring UniqueSite and Control Change Requirements; AEC−Q101 Qualified andPPAP Capable
•These Devices are Pb−Free, Halogen Free/BFR Free and are RoHSCompliant

3.Typical Applications
•RF Signal ESD Protection
•Near Field Communications
•USB 3.x Vbus Protection
