MP2143DJ-LF-Z 100% Original Switching Voltage Regulators 3A, 5.5V, 1.2MHz Sync Stp-Dwn Swtchr

1.DESCRIPTION
The MP2143 is a monolithic, step-down, switchmode
converter with internal power MOSFETs.
It can achieve up to 3A continuous output
current from a 2.5V–to-5.5V input voltage with
excellent load and line regulation. The output
voltage can be regulated as low as 0.6V.
Constant-on-time control provides fast transient
response and eases loop stabilization. Faultcondition
protections include cycle-by-cycle
current limiting and thermal shutdown.
The MP2143 is available in small TSOT23-8
package and requires only a minimal number of
readily-available standard external components.
The MP2143 is ideal for a wide range of
applications including high-performance DSPs,
FPGAs, smartphones, portable instruments,and DVD drivers.

2. FEATURES
 Wide 2.5V-to-5.5V Operating Input Range
 Output Voltage as Low as 0.6V
 100% Duty Cycle in Dropout
 Up to 3A Output Current
 Low IQ: 40µA
 80mΩ and 40mΩ Internal Power MOSFET
Switches
 Default 1.2MHz Switching Frequency
 EN and Power-Good for Power Sequencing
 Cycle-by-Cycle Over-Current Protection
 Auto Discharge at Power Off
 Short-Circuit Protect with Hiccup Mode
 Stable with Low-ESR Output Ceramic
Capacitors
 Available in a TSOT23-8 Package

3.APPLICATIONS
 Low Voltage I/O System Power
 Handheld/Battery-powered Systems
 Wireless/Networking Cards

4.TYPICAL APPLICATION

5.
